Author Archives: TimL

API

TimL • 2018/12/18

The Noodle API is best obtained from a running system with standard Database and Web Browser Tools, but by request we maintain this static approximation.

IWA Debug

TimL • 2018/11/16

Microsoft checklist here.

Server list SPNs:

setspn -l %NoodleServiceAccount

Client list cached tickets:

klist get HTTP/%noodle.domain.tld

Client uncache tickets:

klist purge

The following information can be obtained with Wireshark;

 [truncated]Authorization: Negotiate YIG...NER
    GSS-API Generic Security Service Application Program Interface
        OID: 1.3.6.1.5.5.2 (SPNEGO - Simple Protected Negotiation)
        Simple Protected Negotiation
            negTokenInit
                mechTypes: 4 items
                    MechType: 1.2.840.48018.1.2.2 (MS KRB5 - Microsoft Kerberos 5)
                    MechType: 1.2.840.113554.1.2.2 (KRB5 - Kerberos 5)
                    MechType: 1.3.6.1.4.1.311.2.2.30 (NEGOEX - SPNEGO Extended Negotiation Security Mechanism)
                    MechType: 1.3.6.1.4.1.311.2.2.10 (NTLMSSP - Microsoft NTLM Security Support Provider)
                mechToken: 6092a864886...
                krb5_blob: 6092a864886...
                    KRB5 OID: 1.2.840.113554.1.2.2 (KRB5 - Kerberos 5)
                    krb5_tok_id: KRB5_AP_REQ (0x0001)
                    Kerberos
                        ap-req
                            pvno: 5
                            msg-type: krb-ap-req (14)
                            Padding: 0
                            ap-options: 20000000 (mutual-required)
                                0... .... = reserved: False
                                .0.. .... = use-session-key: False
                                ..1. .... = mutual-required: True
                            ticket
                                tkt-vno: 5
                                realm: INTRA.NET
                                sname
                                    name-type: kRB5-NT-SRV-INST (2)
                                    sname-string: 2 items
                                        SNameString: HTTP
                                        SNameString: intra.net
                                enc-part
                                    etype: eTYPE-ARCFOUR-HMAC-MD5 (23)
                                    kvno: 2
                                    cipher: 678ed5435c9ec4d6...
                            authenticator
                                etype: eTYPE-ARCFOUR-HMAC-MD5 (23)
                                cipher: 62a133014138848d900d436...

SAML Debug

TimL • 2018/11/16

The following information can be obtained with Wireshark or with Noodle DEBUG;

https://intranet.onelogin.com/trust/saml2/http-post/sso/699546?SAMLRequest=fVLLbtsw...%2FkD&RelayState=https%3A%2F%2Fintra.net%2FSAML.po

Should be sent to the IdP which before it is deflated and base 64 encoded looks like

<samlp:AuthnRequest xmlns:samlp="urn:oasis:names:tc:SAML:2.0:protocol" xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" ID="-5abe3a1a-1671d27aa18--8000" Version="2.0" IssueInstant="2018-11-16T15:33:17Z" ProviderName="Noodle" Destination="https://intranet.onelogin.com/trust/saml2/http-post/sso/699546" ProtocolBinding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST" AssertionConsumerServiceURL="https://intra.net/SAML.po">
    <saml:Issuer>Noodle</saml:Issuer>
    <samlp:NameIDPolicy Format="urn:oasis:names:tc:SAML:2.0:nameid-format:encrypted" AllowCreate="true" />
    <samlp:RequestedAuthnContext Comparison="false">
        <saml:AuthnContextClassRef>urn:oasis:names:tc:SAML:2.0:ac:classes:PasswordProtectedTransport</saml:AuthnContextClassRef>
    </samlp:RequestedAuthnContext>
</samlp:AuthnRequest>

The IdP should reply with "Content-Type: application/x-www-form-urlencoded" containing "SAMLResponse: PHN...fCg==" which when base 64 decoded looks like

<samlp:Response xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" xmlns:samlp="urn:oasis:names:tc:SAML:2.0:protocol" ID="R6229535893ec8f41746de8cd0bb42fe1008d88a7" Version="2.0" IssueInstant="2018-11-16T15:33:18Z" Destination="{recipient}" InResponseTo="-5abe3a1a-1671d27aa18--8000">
    <saml:Issuer>https://app.onelogin.com/saml/metadata/699546</saml:Issuer>
    <samlp:Status>
        <samlp:StatusCode Value="urn:oasis:names:tc:SAML:2.0:status:Success" />
    </samlp:Status>
    <saml:Assertion xmlns:saml="urn:oasis:names:tc:SAML:2.0:assertion" xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" Version="2.0" ID="pfx95004805-783d-f0ee-f32d-17d50ca7ef90" IssueInstant="2018-11-16T15:33:18Z">
        <saml:Issuer>https://app.onelogin.com/saml/metadata/699546</saml:Issuer>
        <ds:Signature xmlns:ds="http://www.w3.org/2000/09/xmldsig#">
            <ds:SignedInfo>
                <ds:CanonicalizationMethod Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#" />
                <ds:SignatureMethod Algorithm="http://www.w3.org/2000/09/xmldsig#rsa-sha1" />
                <ds:Reference URI="#pfx95004805-783d-f0ee-f32d-17d50ca7ef90">
                    <ds:Transforms>
                        <ds:Transform Algorithm="http://www.w3.org/2000/09/xmldsig#enveloped-signature" />
                        <ds:Transform Algorithm="http://www.w3.org/2001/10/xml-exc-c14n#" />
                    </ds:Transforms>
                    <ds:DigestMethod Algorithm="http://www.w3.org/2000/09/xmldsig#sha1" />
                    <ds:DigestValue>uCsDHp/wXNnMIz7nkq2D7OF81zY=</ds:DigestValue>
                </ds:Reference>
            </ds:SignedInfo>
            <ds:SignatureValue>QbDsbkTMULdxYmiV8lu64jUE4BNj7ETQvUhjlgHrbaUKMaUdnluJma8T9jh8WOUEQw+Of/MGP4hMJE18f2XOJJK3X3VQnlggE5z98xjHrP0SugRH+elgQpOVkB9ht685UXtzRF6SVAIwstOGphOgqgGRwrG9fPQpN6DAKr00IOc6ItM7cbhVnA+EA8iHP8WP0n+VZXkdub9Sb/tgVkimih3/7DZPIWi6FpmlsTN88mlxBXJKnslr1Iw0ZLqLjR5dJSFz7SHrkBijirFf/kOydoQeOQrRS+6XzOmXayWCP2hHWXVvr5Ye1GbDZyjKTxMpObc+Lv6nj7llC1Mal2M0cw==</ds:SignatureValue>
            <ds:KeyInfo>
                <ds:X509Data>
                    <ds:X509Certificate>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</ds:X509Certificate>
                </ds:X509Data>
            </ds:KeyInfo>
        </ds:Signature>
        <saml:Subject>
            <saml:NameID Format="urn:oasis:names:tc:SAML:1.1:nameid-format:emailAddress">tim@intra.net</saml:NameID>
            <saml:SubjectConfirmation Method="urn:oasis:names:tc:SAML:2.0:cm:bearer">
                <saml:SubjectConfirmationData NotOnOrAfter="2018-11-16T15:36:18Z" Recipient="{recipient}" InResponseTo="-5abe3a1a-1671d27aa18--8000" />
            </saml:SubjectConfirmation>
        </saml:Subject>
        <saml:Conditions NotBefore="2018-11-16T15:30:18Z" NotOnOrAfter="2018-11-16T15:36:18Z">
            <saml:AudienceRestriction>
                <saml:Audience>{audience}</saml:Audience>
            </saml:AudienceRestriction>
        </saml:Conditions>
        <saml:AuthnStatement AuthnInstant="2018-11-16T15:33:17Z" SessionNotOnOrAfter="2018-11-17T15:33:18Z" SessionIndex="_c9a77760-cbdb-0136-fc65-0233ce1b6e10">
            <saml:AuthnContext>
                <saml:AuthnContextClassRef>urn:oasis:names:tc:SAML:2.0:ac:classes:PasswordProtectedTransport</saml:AuthnContextClassRef>
            </saml:AuthnContext>
        </saml:AuthnStatement>
    </saml:Assertion>
</samlp:Response>

Integrated Windows Authentication (IWA)

TimL • 2018/11/14

Overview

IWA allows for SSO using the Operating System users credentials.

Prerequisites

LDAP users have been successfully populated from AD; if not please refer to the AD Configuration Guide.

Quick reference

setspn -U -S HTTP/%noodle.domain.tld %service_account
Add Noodle to "Microsoft Internet Explorer > Tools > Internet Options > Security > Local intranet > Sites > Advanced"
Use https://yourNoodle.tld/SPNEGO.po

Supported configurations

Browsers

Microsoft Internet Explorer, Mozilla Firefox, Google Chrome
Note: Microsoft Edge does not support this feature.

Protocols

Kerberos in SPNEGO in GSS-API (RFC 2478)
Note: NTLM, and NegoExts are not supported.

The "Please enable the Kerberos Security Support Provider (SSP)" error indicates the wrong protocol was used.

Endpoints

AD, Azure, and F5
Note: Others may work but have not been tested

Server configuration

Define the appropriate SPN for the account which Noodle is using to bind to LDAP using one of the 4 options;

Within the AD Users and Groups snap-in Navigate to Noodle’s service (admin) account and set the follow attribute:
- servicePrincipalName = HTTP/%noodle.domain.tld
This may also be set via command line:
- setspn -U -S HTTP/%noodle.domain.tld %service_account
For Windows server 2008R2 or older command line instead use
- setspn -A HTTP/%noodle.domain.tld@DOMAIN.TLD %service_account
For AES instead of RC4
- ktpass -out noodle.keytab -mapUser NoodleServiceAccount@%DOMAIN.TLD -pass %NoodleServiceAccountPassword -mapOp set +DumpSalt -crypto AES256-SHA1 -ptype KRB5_NT_PRINCIPAL -princ HTTP/%my.noodle.tld@%DOMAIN.TLD
- Check the box "This account supports Kerberos AES 256 bit encryption" in the NoodleServiceAccount user.

Note:

Logins from the AD Kerberos Server itself are not supported because Windows will attempt NTLM.
Using an IP in place pf a domain name is not supported because Windows will attempt NTLM.
For local installs, non-primary domains can be used with IWA by placing “IgnoreIWADomain = true” into noodle.properties
Use an A record in the DNS, CNAMEs will break Kerberos
- check with
  - nslookup domain.intra.net
- workaround with
  - HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Internet Explorer\Main\FeatureControl\FEATURE_USE_CNAME_FOR_SPN_KB911149=true
Enable NTP services If the Noodle logs contain the following;
- .intranet,ERROR+ Caused by: KrbException: Clock skew too great (37)

Browser configuration

The next step in enabling IWA requires browser configurations to attempt authentication with the Noodle intranet website.

Once the configuration is in place users will need to access Noodle via the SPNEGO.po URL (ie. https://yourNoodle.tld/SPNEGO.po).

The following section of this guide explains this process.

Microsoft Internet Explorer & Google Chrome

Both of these browsers are configured with Microsoft Internet Explorer in "Tools > Internet Options > Security > Local intranet".

Note: If a non-default level is in use be sure “Automatic logon only in Intranet zone” is selected in "the Custom Level".

Next we will need to add the URL of your Noodle instance in "Sites > Advanced".

Mozilla Firefox

Enter “about:config” in the address bar, press “Enter”, and click “I Accept the Risk” when prompted.

Next, search for “auth.trusted”, enter your Noodle URL in the attribute entitled “network.negotiate-auth.trusted-uris” and select OK.

At this point IWA should be fully operational for your Noodle Intranet site!

Security Assertion Markup Language (SAML)

TimL • 2018/11/14

Overview

SAML allows for SSO using the Web Browser users credentials.

Noodle Prerequisites

If AD is being used, LDAP users should have already been populated within Noodle.

Quick reference

Save your IdP URL and fingerprint in your SP (Noodle)
Use https://yourNoodle.tld/SAML.po in your IdP settings and Web Browser.

Supported IdPs

Onelogin, Okta, and Azure
Note: Contact us for assistance integrating Other IdPs.

Noodle Configuration

In Noodle navigate to “System Tools > Settings > Single Sign-On”

Both URL & fingerprint will be supplied by your IdP vendor. Your IdP may provide an XML file which contains the URL and certificate, to convert the certificate into a SHA-1 fingerprint there are some online SAML tools:

Format Certificate

Calculate Fingerprint

IdP Configuration

Your IdP will require a location to direct SAML responses, use https://yourNoodle.tld/SAML.po. Noodle will be compatible with the default settings of most IdPs.

OneLogin

Navigate to "Administration > Applications > Add App"
Search for "SAML Test Connector (IdP)"
setting tabs
- Info (all optional)
- Configuration
  - ACS (Consumer) URL Validator = .*
  - ACS (Consumer) URL = https://yourNoodle.tld/SAML.po
  - the rest can be left blank
- Parameters
  - Configured by admin
    - NameID (fka Email) = Email
- Rules (all optional)
- SSO
  - X.509 Certificate = 2048-bit
    - View details will show the fingerprint
  - SAML Signature Algorithm = SHA-1
  - SAML 2.0 Endpoint (HTTP)
    - This is the URL to save in Noodle
- Access (all optional)
- Users (make sure you add some)
- Privileges (all optional)

Azure

Azure Active Directory > Enterprise applications > New Application
Non-gallery Application > Name can be anything > 2 Single sign on > SAML
- set "Identifier (Entity ID)" to the domain name for the Noodle instance
- set the "Reply URL" to https://yourNoodle.tld/SAML.po
- copy the "Thumbprint" and "Login URL" to put in the Noodle settings

Integration

TimL • 2018/10/16

Noodle supports the following integrations:

Authentication
- Microsoft Active Directory (LDAP)
- OneLogin (SAML)
- Okta (SAML)
- F5 (LDAP)
Media
- Unsplash
- Youtube
- Vimeo
Files
- Google Drive (OAuth)
Calendars (iCal)
- Google
- Microsoft
Scripting (bash)
- server scripting (HTTP)
- Ubuntu (WebDAV)
- Let's Encrypt (ACME)
email (SMTP)
- Postfix
- MS Exchange
- etc
RDBMS (SQL)
- PostgreSQL
- MS SQL
- MareaDB
- MySQL
- CockroachDB + Ceph
- Oracle
Web Browsers
- Firefox
- Chromium
Indexing (CLI)
- TensorFlow
- MS Office
- Adobe
- LibreOffice
- OpenAI Whisper
- Tesseract
- etc
UI Customization (JS/CSS)
- Twitter
- Weather
- RSS
- etc

Configuring PostgreSQL

TimL • 2018/06/20

If you manually installed PostgreSQL it should have the following done before Noodle connects to it

permit password authentication via 127.0.0.1 in pg_hba.conf
run init.sql

GDPR

TimL • 2018/04/30

GDPR checklist;

Local

We hold payment information optionally provided by clients, and share it with no one. we use it to charge for our software service.
We hold at least one pice of contact information to update payment information.
Data is stored on our accounting computer
This is our publicly accessible policy
We have a DPO
Our staff and management is aware of this document
We use modern and up to date security.
We appoint clients as their own representatives in the EU
If ever we become aware of a personal data breach our customers and local authorities will be made aware.
customers can verify and update information by simply asking.
We review this policy annually or as required.
We understand when DPIA is required

Hosted

Data is stored-in / removed-from a location of the clients request.

Drive

TimL • 2018/02/09

Create a drive key and secret
Put them in "System Tools > Settings > General > Google Drive OAuth"
1. Note that OAuth requires your Noodle server to be accessed via a public domain
Enable in the "Administration > Properties" of the folder you want to connect.
View the folder and follow the prompts.

Bug Bounty

TimL • 2018/02/05

Vialect Bug Bounty;

Contact us and let us know you are interested.
Qualification
- Confine aggressive/damaging testing to a local install
- Keep your findings confidential until the week after we fix the bug (same day we hope)
- We pay whenever we make a change as a result of your bug report.
Send us a report with enough information for us to reproduce the bug of whatever class
- RCE Remote code execution
- EoP Elevation of privilege
- ID Information disclosure
- DoS Denial of service
We will reward you (You will not be prosecuted)
- Public credit and thanks
- Payment (varies by severity and location of the bug up to $1,000 USD)

We thank VioPoint and All Covered for Testing Noodle.

Noodle Help Site

Helping you use your Noodle

Author Archives: TimL

API

IWA Debug

SAML Debug

Integrated Windows Authentication (IWA)

Overview

Prerequisites

Quick reference

Supported configurations

Browsers

Protocols

Endpoints

Server configuration

Browser configuration

Microsoft Internet Explorer & Google Chrome

Mozilla Firefox

Security Assertion Markup Language (SAML)

Overview

Noodle Prerequisites

Quick reference

Supported IdPs

Noodle Configuration

IdP Configuration

OneLogin

Azure

Integration

Configuring PostgreSQL

GDPR

Drive

Bug Bounty
